[AHD Signal] and [Analog Signal] are optional:
(These two signals are not compatible, and most devices cannot simultaneously support both for display) Please confirm which signal your monitor or recorder uses before making a purchase.
| Model | SF-5100 |
| Imaging chip | 1/2.9 "CMOS |
| Frame number | □ 25 fps □ 30fps |
| Effective pixels | 1920 (H) x 1080 (V) |
| Pixel size | 2.8 μm x 2.8 μm |
| Scanning system | Progressive Scan |
| Synchronous system | Internal Synchronization |
| Resolution | 1080P |
| Gamma | 0.45 |
| AGC | Auto |
| Dynamic Response | 81DB |
| White balance | Auto |
| Electronic shutter | 1/25 ～ 1/50,000 Seconds |
| BLC | Auto |
| Operating temperature | –20 ℃ ~ 70 ℃, RH95%MAX |
| Storage temperature | –40 ℃ ~ 80 ℃, RH95%MAX |
| Power supply | DC12-32V |
| Waterproof level | IP69K |
| Horizontal angle | 150 ° |
| Audio | built-in |
| Minimum illness | □ 0.1 Lux/F1.2 □ 0Lux LED On |
| Image mode | □ Mirror □ Normal |
