| Model | SF-7099MGD |
| Screen size | 10.1 inch |
| Resolution | 800 X (RGB) X 480 （1024 X (RGB) X 600optional ） |
| Contrast | 500:1 |
| Brightness | 450cd/m |
| Video input | Three -way video input (optional) |
| Trigger control | Two reversing triggers (optional) |
| Video format | CVBS(PAL/NTSC) |
| Power supply | DC10V~36V |
| Operating temperature | -20~+70°C, RH 95%MAX |
| Storage temperature | -30~+80°C, RH 95%MAX |
| Installation method | Bracket, boom, headrest frame (optional) |
| Interface | Aviation head, RCA head, S terminal (optional) |
| Operation method | Panel, remote control |
| OSD | Graphic menu / reversing assist line switch |
| Reverse delay 0~15 settings / image mirror settings | |
| Multi -national menu language optional | |
| Image effect adjustment | |
| Feature | Automatic brightness adjustment |
| camera supports independent separate power supply | |
|
Anti -interference design / with a sun cover high temperature safety fire prevention material |
|
| Size | 177(L)X122(W)X26MM(T) |
